Features:
1.low surface oxygen characteristics;
2.strong adhesion;
3.good electrical conductivity, can eliminate electromagnetic (EMI) interference, isolate electromagnetic waves from harming the human body, and avoid the influence of unwanted voltage and current on Electric energy;
4. In addition, it has a good effect on static discharge after grounding.
| Item | TMS-CF001 |
| Color | Copper |
| Carrier | Copper Foil |
| Adhesive | Acrylic Adhesive |
| Carrier Thickness(mm) | 0.020-0.10 |
| Total Thickness(mm) | 0.05-0.18 |
| Resistance(Ω) | <0.05 |
| Initial Tack(kg/inch) | ≥0.7 |
| Application Temperature(℃) | 20~120 |
| Shielding Effectiveness(DB) | 55-88 |
| Width(mm) | Custom as customer request |
| Length(mm) | Custom as customer request |
